Description
- Hinged idler wheel cover
- Miter gauge turns and locks for common angles 45° left and right
- Abrasive belt unit does the work of a jig-saw, copying saw or hand file while removing material and finishing at the same time, allows the operator to get into small oppenings plus handle odd shapes and angles
- Removable platen allows for sanding, grinding or finishing of outside curves or odd shaped work pieces on the belt
- Grind, sand or finish large work pieces on the disc unit fast and efficiently; combined with the tilting table, the operator can chamfer or bevel, table is slotted to accept miter gauge
- When using non-woven synthetic belts the operator can blend, buff or finish metal surfaces in addition to defuzzing wood surfaces
- Miter gauge
- Cast iron tilting table
- Cast construction
- Heavy duty steel base and rubber feet
- Removable platen
- Adjustable dust deflector and dust chute
- 2 year warranty
Specifications:
- Model Number: J-4002
- Brand: Jet
- Height: 23.7"
- Width: 14"
- Length: 22.7"
- Net Weight: 62 lbs
- Gross Weight: 62 lbs
- Motor: 1/3HP, 115V, 1ph
- Belt Size: 1 x 42
- Belt Speed: 3000
- Belt Table Size: 6-1/8 x 7-1/8
- Disc Table Size: 4 x 10
- Belt Table Tilt: 45° out
- Disc Table Tilt: 45° out
- Disc Diameter: 8
- Disc Speed: 1725
- Dust Collection Outlet Diameter: 1-1/2
- Machine Dimensions: 15 x 24-1/2 x 19-1/2
