Laguna DP|20 20" Drill Press

Laguna DP|20 20" Drill Press

Introducing the new DP20: Where Industrial Power Meets Modern Design. The DP20 is the latest innovation in our classic line, engineered for industrial-grade performance. At its heart is a robust 1.5 HP Pulse Width Modulation (PWM) motor, delivering constant torque across a full speed range of 60 to 3600 RPM, making it perfect for the most demanding applications in wood, metal, plastics, and other materials.

The state-of-the-art Touch Screen Smart Panel features a unique blue LCD digital readout, providing real-time RPM, Load, and Quill Depth, enhancing functionality and aesthetics. The large 3-3/4″ x 6-7/8″ touch screen is a standout feature among drill presses in this range, surpassing competitors with its size and touch capability.

Features:

Experience unmatched efficiency with the Auto-Start function. This function activates the drill press when the quill is lowered and stops it when raised. Achieve precise and consistent drilling depth with the electronic depth setting or mechanical depth stop.

Safety is a top priority with a chuck key holder equipped with a sensor that locks out the Auto-Start function during bit changes. The Auto Reverse function is another standout feature, specifically designed for tapping to automatically reverse the tap when it reaches the preset depth.

The extra-large 15" x 22" cast iron worktable can tilt left and right up to 90 degrees and rotate 360 degrees, providing versatile support for different workpieces and multiple clamping options. It also features an onboard high-output 5W LED work light and crosshair lasers to ensure precise material positioning and optimal visibility. Elevate your craftsmanship with the DP20 - the pinnacle of performance and modern design for drill presses.

• Touch Screen Smart Panel: Intuitive interface with blue LCD digital readout.
• 1.5 hp PWM Motor: Constant torque with forward and reverse functions.
• Auto-Start Function: Starts and stops with the movement of the quill.
• Precision Depth Control: Electronic depth setting.
• Advanced Safety Features: Chuck key holder with a sensor that locks out Auto-Start function during bit changes.
• Customizable Memory Settings: Five programmable speed and depth settings.
• Extended Quill Travel: 6 inches of precise drilling capacity.
• Versatile Worktable: Large 15” x 22” cast iron table tilts up to 90 degrees left and right, rotates 360 degrees, with T-slots and 10 clamping holes.
• High-Output LED Work Light: Onboard 5W LED for optimal visibility.
• Crosshair Lasers: Ensures precise material positioning.
• Modern Design: Sleek aesthetic from headstock to table control handles.
• User-Selectable Screen Increments: Displays in Fractional Inch, Decimal Inch, or Decimal Millimeter.
• Cross Hair Laser Material Positioning
• 6′ Power Cord
• Audible Button Confirmation Tone

Additional Details:
