Out of Stock - Pre-order today!

Powermatic PM1000t 52" Table Saw 1-3/4Hp 1Ph 115/230V Armorglide

(No reviews yet) Write a Review
SKU:
P1791001KT
UPC:
19907107965
MPN:
pm1-1791001kt
Shipping:
$300.00 (Fixed Shipping Cost)
On Sale
  • Powermatic PM1000t 52" Table Saw 1-3/4Hp 1Ph 115/230V Armorglide
  • Powermatic PM1000t 52" Table Saw 1-3/4Hp 1Ph 115/230V Armorglide
Now: $3,239.99
Was: $3,599.99
— You save $360.00

Description

Powermatic PM1000t 52" Table Saw 1-3/4Hp 1Ph 115/230V Armorglide

Evolution represents a process that is never fully complete. For a woodworker, inspirations evolve as life experiences shape our creativity. Skills evolve as we share tips and techniques with friends and mentors. And our workshops evolve as we refine our skills. The PM1000 cabinet table saw is an example of this. Now featuring our ArmorGlide Technology that is low-friction and rust-resistant, the PM1000 redefines the limits of design, innovation, and durability.

Features

  • ArmorGlide Technology gives you a low-friction, industrial-grade coating on the work surface that is rust-resistant, requires less maintenance, and gives you more control
  • Miter gauge is built with robust materials with many positive stops for the most commonly used angles
  • Blade surround and collection hose provide an unobstructed path, maximizing dust collection
  • Arbor lock allows for one-handed blade changes with minimal tools
  • Conveniently located hands-free power switch
  • Ergonomically designed 7” handwheels provide momentum, making blade height and bevel adjustments easy
  • Exclusive Accu-Fence provides rigidity and precision
  • Precision ground cast iron work surface features a beveled edge for smoother operation
  • Requires only 115V connection for easy installation
  • The poly-V belt drive system reduces vibration and maximizes efficiency

Specifications

Stock Number PM1-1791001KT
Arbor Diameter (In.) 5/8
Arbor Speed (RPM) 4200
Blade Diameter (In.) 10
Dust Collection Minimum CFM Required (CFM) 350
Dust Port Outside Diameter (In.) 4
Gross Weight (Lbs) 289
Maximum Depth of Cut at 45 Degrees (In.) 2-1/8
Maximum Depth of Cut (In.) 2-1/8 or 3-1/8
Maximum Diameter of Dado (In.) 8
Maximum Rip Left of Blade (In.) 12
Maximum Rip Right of Blade (In.) 52
Maximum Width of Dado (In.) 13/16
Miter Gauge Type T-Slot with Stops
Model Number PM1000T
Motor Power (HP) 1-3/4
Motor Voltage (V.) 115/230
Net Weight (Lbs.) 289
Overall Dimensions (L x W x H) (In.) 43 x 83 x 44
Prewired Voltage (V.) 115
Recommended Circuit Size (Amps.) 20
Style (Type) Cabinet
Table Height from Floor (In.) 34-1/4
Table in Front of Saw Blade at Maximum Depth of Cut (In.) 10
Table Size (L x W) (In.) 20 x 27
Table Type Cast Iron
